Genesis

Call Us

The Genesis comes with:

Wireless GNSS

1.25 kg (2.75 lbs)

  • Interface Cable

    100 g (.22 lbs)

  • Power Supply

    227 g (0.5 lbs)

  • Case

    Empty Case: 2.9 kg (6.4 lbs)

    Shipping Weight: 6.4 kg (14.1 lbs)

    Shipping Dims (in cardboard box):

    52 cm (20’’) x 42 cm (16’’) x 23 cm (9’’)

  • Rail Mount

    100 g (.22 lbs)

    Fits 22-25 mm (7/8-1’’) diameter tubes

  • USB Wireless Transceiver

    10 g (0.02 lbs)

Genesis Includes

  • Satellite Antenna
  • Status LEDs
  • Serial Port & Power
  • Power Switch
  • RF Antenna
GNSS Receiver
Signals Received GPS (U.S.A.) GLONASS (Russia) BeiDou (China) Galileo (Europe) QZSS (Japan)
Channels 327
SBAS Tracking 3-Channel, parallel
Satellite-Based WAAS Augmentation Systems (SBAS) Supported WAAS (N. America) EGNOS (Europe) MSAS (Japan) GAGAN (India)
L-Band 0.08m (3.15 in)
RTK Not Supported
Radio Beacon Not Supported
Sample Rate 10 Hz, default (1 Hz available; 20 Hz via upgrade)
Cold Start < 60s typical (all unknown)
Hot Start < 10s typical (all known)
Warm Start < 30s typical (no ephemeris)
DGPS dropout correction Up to 40 min sub-metre accuracy with lost/ blocked DGPS
Communications
Ports RS-232 via one physical port and one wireless port
Output NMEA 0183 @ 19200 baud
Range (outdoor, line-of-sight) 50m (164 ft)
Range (indoor) 20m (66 ft)
Wireless 2.4 GHz
Environmental
Operating Temperature -40°C to 70°C (-40F to 158F)
Storage Temperature -40°C to 85°C (-40F to 185F)
Humidity 95% non-condensing
Enclosure IP67
Mechanical
Height 18 cm (7.1 in)
Diameter 9 cm (3.5 in)
Weight 1.2 kg (2 lb, 11 oz)
Shipping Weight 4.8 kg (10.5 lb) (with case & all components) 4.8 kg (10.5 lb)
Mounting 1”-14 UNS 2A female, 3/4” max thread engagement. Rail mount for 7/8”(22mm) or 1” (25mm) rails included. Mag-mount also available.
Battery Life 6 hours
Position Accuracy
RMS (67%) 2DRMS (95%)
Autonomous, no SA 1.2m (3.9 ft) 2.5 m (8 ft)
SBAS (WAAS) 0.3 m (1 ft) 0.6 m (2 ft)
L-Band 2,3 0.04 m (1.5 in) 0.08 m (3 in)
0.15 m (6 in) 0.3m (1 ft)
0.5m (20 in) 1m (39 in)
